Milesight UG65 Helium hotspot Miner is the Full Helium version of their well-established UG65 LoRaWAN gateway. It is an industrial production grade with an IP65 enclosure and capable to work in a harsh environment between -40 and +70 degrees Celsius and with up to 95% humidity.

Milesight UG65 is a full miner which supports both POC and data transfer. Adopting the SX1302 LoRa chip and high-performance quad-core CPU, UG65 supports connection with more than 2000 nodes.

  • Quad-core industrial processor with big memory
  • Equip with SX1302 chip, handing a higher amount of traffic with lower consumption
  • 8 half/full-duplex channels
  • IP65 enclosure and industrial design for parts of outdoor environment applications like eaves
  • Enable security communication with multiple VPNs like IPsec/OpenVPN/L2TP/PPTP/DMVPN
  • Compatible with Helium people’s network
  • Detect and analyze the noise level and provide intuitive diagram for deployment
  • Built-in network server and MQTT/HTTP/HTTPS API for easily integration
  • Embedded Python SDK for users secondary development
  • Fast and user-friendly programming by Node-RED development tool

UG65 LoRaWAN® Hotspot Datasheet

SKU: IOT-G65H

Helium LongFi

Compatible with Helium LongFi, a technology benefits from all advantages and features of LoRaWAN® network while adding the capability for gateway owners to earn HNT (Helium Network Token).

High Performance

  • Quad-core Processor
  • 2 GB DDR4 RAM
  • 32 GB Flash

Adopted NXP industrial-grade quad-core processor, 2 GB big memory, and 32 GB eMMC flash. The Milesight Hotspot Helium Miner provide the top-notch hardware for efficient mining operation

Secure and Reliable

Milesight Hotspot Helium Miner built-in ATECC608 crypto chip provides swarm keys storage, as well as highly-secure authentication and reliable connectivity.

High-Gain Antenna

Enhanced high-gain antenna offers wider network coverage, meaning better Proof of Coverage for increased HNT earnings.

Ultra-low Power Consumption

The maximum power consumption is below 5 W. The electricity usage is similar to a 5 W LED bulb.

How do I earn HNT?

Proof-of-Coverage
Hotspots on the network are randomly and automatically assigned Proof-of-Coverage tests to complete. Passing and witnessing tests earns HNT.
Relay Device Data
Hotspots earn HNT for transferring device data over the network. The more device data a Hotspot transfers, the more it earns.
Consensus Groups
Trusted Hotspots are randomly elected to Consensus Groups, earning HNT by validating transactions and adding blocks to the blockchain.
