| Model | POE-Switch0504GD |
POE-Switch1008 -Solar |
POE-SW708GM -DC12V |
| Power Input | DC12V~48V | DC12V~48V | DC 12V~57V |
| PoE Ports | 4 | 8 | 8 |
| PoE Standard | IEEE802.3af/at | IEEE802.3af/at | IEEE802.3af/at/bt |
| Total PoE Budget | 60W (DC12V) 120W (DC24V/48V) |
80W (DC12V) 120W (DC24V) 240W (DC48V) |
60W (DC12V) 120W (DC24V) 240W (DC48V) |
| Management | / | / | √ |
| PoE Port Control | / | / | √ |
| RS485 | / | / | √ |
| DC12V/24V Output | / | / | √ |
|
|
|
|
|---|---|---|---|
| Model | POE-SW708GM |
POE-SW708GM -DC12V |
POE-SW716GM -10G |
| Power Input | DC48V~57V | DC12V~57V | DC 48V~57V |
| SFP Ports | 2 1000Base-X Ports | 2 1000Base-X Ports | 4 10G Ports |
| PoE Ports | 8 | 8 | 16 |
| PoE++ Ports | 4 BT 90W Ports | 1 BT 90W Ports | / |
| Total PoE Budget | 360W |
80W (DC12V) 120W (DC24V) 240W (DC48V) |
360W |
| L2/L3 Management | L2 Management | L2 Management | L3 Management |
| RS485 | / | / | √ |
| DC12V/24V Output | / | √ | / |
 |
|
|
|---|---|---|
| Model | POE-SW508G | POE-Switch1108GP |
| Power Input | DC 48V~56V | AC110V~240V |
| PoE Ports | 8 Gigabit | 2 Gigabit + 6* 10/100Mbps |
| PoE++ Ports | 4 BT 90W Ports | 2 BT 60W Ports |
| Passive 24V POE | / | 80W (DC12V) 120W (DC24V) 240W (DC48V) |
| Total PoE Budget | 120W | / |
| Uplink Ports | 2 Gigabit SFP |
1 Gigabit SFP + 2 Gigabit Uplink |
| Waterproof | / | / |
| Installation Method | DIN-Rail | Pole/Wall-Mount |
